Product Summary

The LTN101NT02 is a color active matrix TFT (Thin Film Transistor) liquid crystal display (LCD) that uses amorphous silicon TFT as switching devices.

Parametrics

Absolute maximum ratings: (1)Vnop Vibration (non-operating):2.41G; (2)Snop Shock( non-operating ):240G; (3)Operating temperate(Temperature of glass surface):0℃ to 50℃; (4)Storage temperate:-20℃ to 60℃.

Features

Features: (1)High contrast ratio; (2)WSVGA (1024 x 600 pixels ) resolution; (3)Low power consumption; (4)Fast Response; (5)LED Back Light with embedded LED Driver; (6)DE (Data enable) only mode; (7)3.3V LVDS Interface ; (8)Onboard EEDID chip; (9)Green product (RoHS compliant).

Diagrams
