Product Summary

The EL320.240.36-HB thin film electroluminescent (EL) display is a highper formance alternative to quarter-VGA LCDs and is the ideal solution in demanding applications where superior visual performance and environmental ruggedness are critical. The EL320.240.36-HB utilizes Planar’s proprietary Integral Contrast Enhancement (ICEÔ) technology to achieve unparalleled image quality without the use of expensive filters. This small graphics display excels in a wide range of ambient lighting environments while effectively eliminating the blooming common to other high-bright displays.

Parametrics

Absolute maximum ratings: (1)Absolute Input Voltage Range: -0.3 V min and 5.5 V max at VL= 5.0 V; (2)Video logic high voltage: 70% VL min and 100% VL max when all input thresholds are CMOS; (3)Video logic low voltage: 0 to 20% VL; (4)Video logic input current: ±0.25 mA max at ±0.75 mA max Selftest; (5)Input capacitance: 15 pF max.

Features

Features: (1)Excellent visual performance: High brightness and contrast, Wide viewing angle > 160°; (2)Rapid display response < 1 ms; (3)Frame buffer; (4)Space efficient mechanical package; (5)Low EMI emissions; (6)Extremely rugged and durable; (7)Reliable, long operating life; (8)4-bit LCD-type interface.

Diagrams

EL32D1
EL32D1
