Product Summary
The CA3140E is the integrated circuit operational amplifiers that combine the advantages of high voltage PMOS transistors with high voltage bipolar transistors on a single monolithic chip.
Parametrics
Absolute maximum ratings: (1)DC Supply Voltage (Between V+ and V- Terminals): 36V; (2)Differential Mode Input Voltage: 8V; (3)DC Input Voltage: (V+ +8V) To (V- -0.5V); (4)Input Terminal Current: 1mA; (5)Output Short Circuit Duration: Indefinite.
Features
Features: (1)MOSFET Input Stage: Very High Input Impedance (ZIN) -1.5TΩ (Typ), Very Low Input Current (Il) -10pA (Typ) at ±15V, Wide Common Mode Input Voltage Range (VlCR) - Can be Swung 0.5V Below Negative Supply Voltage Rail, Output Swing Complements Input Common Mode Range; (2)Directly Replaces Industry Type 741 in Most Applications.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 CA3140E |
|
IC OPAMP DUAL BIMOS 4.5MHZ 8-DIP |
Data Sheet |
Negotiable |
|
||||||||||||
 |
CA3140EZ |
Intersil |
Operational Amplifiers - Op Amps W/ANNEAL OPAMP 4.5MH ZLWBIAS0.04NA8PDIPML |
Data Sheet |
|
|
||||||||||||
