Product Summary
The BAT54S is a schottky diode.
Parametrics
Absolute maximum ratings: Features: (1)Maximum Repetitive Reverse Voltage: 30 V; (2)Average Rectified Forward Current 200 mA; (3)Non-repetitive Peak Forward Surge Current Pulse width = 1.0 second: 600 mA; (4)Storage Temperature Range: -55 to +150 ℃; (5)Operating Junction Temperature: 150 ℃.
Features
Features: (1)Breakdown Voltage: 30 V min at IR = 10 μA; (2)Forward Voltage: 240 mV max at IF = 0.1 mA, 320 mV at IF = 1 mA, 400mV at IF = 10 mA, 500mV at IF = 30 mA, 1.0V at IF = 100 mA; (3)Reverse Current: 2 μA at VR =25 V; (4)Total Capacitance: 10 pf at VR = 1V, f = 1.0 MHz; (5)Reverse Recovery Time: 5.0ns at IF = IR = 10 mA, IRR = 1.0 mA, RL = 100Ω.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 BAT54S,235 |
NXP Semiconductors |
Schottky (Diodes & Rectifiers) DIODE SCHTKY TAPE-11 |
Data Sheet |
|
|
||||||||||||
 |
BAT54S_ND87Z |
Fairchild Semiconductor |
Schottky (Diodes & Rectifiers) 30V 200mA |
Data Sheet |
