Product Summary

The ADR280ARTZ-R2 is a 1.2V band gap core reference with excellent line regulation and power supply rejection designed specifically for applications experiencing heavy dynamic supply variations. The applications of the ADR280ARTZ-R2 include list GSM, GPRS, 3G mobile stations, portable battery-operated electronics, low voltage converter references and wireless devices.

Parametrics

ADR280ARTZ-R2 absolute maximum ratings: (1)Supply voltage: 6V; (2)Storage temperature range: -65℃ to +150℃; (3)Operating temperature range: -40℃ to +85℃; (4)Junction temperature range: -65℃ to +150℃; (5)Lead temperature range: 300℃.

Features

ADR280ARTZ-R2 features: (1)1.2V precision output; (2)Excellent line regulation: 2ppm/V typical; (3)High power supply ripple rejection: -80dB at 220Hz; (4)Ultralow power supply current: 16μA maximum; (5)Temperature coefficient: 40ppm/℃ maximum; (6)Low noise, 12.5nV; (7)Operating supply range: 2.4V to 5.5V; (8)Compact 3-lead SOT-23 and SC70 packages.

Diagrams

ADR280ARTZ-R2 pin configuration
