Product Summary

The BSP772T is a N channel vertical power FET with charge pump, ground referenced CMOS compatible input, monolithically integrated in Smart SIPMOS technology.

Parametrics

Absolute maximum ratings: (1)Supply voltage: 40 V; (2)Supply voltage for full short circuit protection Tj = -40 to +150 ℃: 36; (3)Continuous input voltage: -10 to +16 V; (4)Load current: self limited A; (5)Current through input pin (DC): ± 5 mA; (6)Operating temperature: -40 to +150 ℃; (7)Storage temperature: -55 to +150 ℃.

Features

Features: (1)Overload protection; (2)Current limitation; (3)Short circuit protection; (4)Thermal shutdown with restart; (5)Overvoltage protection (including load dump); (6)Fast demagnetization of inductive loads; (7)Reverse battery protection with external resistor; (8)CMOS compatible input; (9)Loss of GND and loss of Vbb protection; (10)ESD - Protection; (11)Very low standby current.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
BSP772T
BSP772T

Infineon Technologies

Power Switch ICs - Power Distribution Smart High Side MINI-PROFET

Data Sheet

0-1: $1.61
1-10: $1.38
10-100: $1.12
100-500: $0.87
